BW 2 Part Cable Glands

Technical Data

Size
Thread Size 'C'
Minimum Length of Thread
Cable Range
MM
INCH
'D'
MAX 'A'
MAX 'B'
20S
20
3/4
10
13.00
15.50
20L
20
3/4
10
14.00
18.50
25L
25
1
10
20.50
26.00
32L
32
1.1/4
10
27.00
33.90
40L
40
1.1/2
15
33.00
41.50
50S
50
2
15
38.50
47.00
50L
50
2
15
44.00
52.00
63S
63
2.1/2
15
51.00
59.20
63L
63
2.1/2
15
56.50
65.50
75S
75
3
15
63.00
74.00
75L
75
3
15
68.50
79.50
90L
90
3.1/2
20
80.50
91.00

Description

Application
 For indoor use with all types of SWA Cable.
Function
 Provide Mechanical Cable Retention & Electrical Wire Continuity Via Armored Wire.
Material
 Brass BS 2874 CZ121 Pb3, any special brass material composition as per customer's requirements.
Optional Threads
 Metric, NPT, BSP.
Finish & Plating
 Brass Natural, Nickel Plated, Chrome Plating, and any special plating as required.
Operating Temperature
 Standard seals -20° C To +80° C.
Standard
 BS 6121
Accessories
 Matching Accessories available like PVC Shrouds, Lock Nuts, Earth Tags, Reducers, Adaptors etc.
